Project Overview
Entrance Requirement
The bank required a controlled entrance capable of distinguishing between employees, approved visitors and unauthorized users while maintaining convenient passage during business hours.
The project requirements included:
- Employee entry through the bank’s credential system
- Visitor release through reception or security personnel
- Anti-tailgating and controlled compartment occupancy
- Multiple operating modes for normal, restricted and locked conditions
- Integration with security, CCTV and intrusion alarm systems
- Clear event logging and door-status feedback
- Safe emergency release and fire alarm response
- Quiet operation near the reception and customer service areas
- Professional finishes suitable for a corporate headquarters
- Reduced drafts and outdoor air exchange in the main lobby
- An accessible side entrance for wheelchairs and approved large-item access
Verified Project Evidence
Key Project Requirements
Render the approved requirement list from the `Entrance Requirement` source content in a separate visual group. Do not invent additional challenges.
Verified Project Evidence
Supplied Automatic Door System
A security automatic revolving door with integrated access control functions was supplied for the bank headquarters.
The system included:
The entrance control logic was coordinated with the bank’s security procedures so authorized personnel could select the appropriate operating mode from the security desk.
- Reinforced revolving door canopy and drum enclosure
- Commercial automatic drive unit
- Security-grade programmable controller
- Central shaft and glazed revolving wings
- Curved laminated safety glass
- Directional activation and presence sensors
- Multi-zone anti-pinch and anti-collision detection
- Employee card reader and credential interface
- Reception and security desk release controls
- Configurable anti-tailgating and occupancy monitoring
- Door-status and alarm output connections
- Normal automatic, controlled-entry, exit-only and full-lock modes
- CCTV, intrusion alarm and building security interfaces
- Emergency stop and project-defined controlled release interfaces
- Fire alarm release interface
- Backup power connection
- Security locking system
- Controlled accessible automatic side entrance
- Complete installation, control and finishing components
Verified Project Evidence
Project Outcome
The completed entrance strengthens access management at the bank headquarters while maintaining an efficient and professional arrival experience for employees and approved visitors.
Credential integration and controlled operating modes give the security team greater oversight of the main lobby entrance. Anti-tailgating functions and status feedback support the building’s security procedures, while the revolving enclosure helps reduce drafts and maintain a more stable lobby environment.
